ETHERNET UP TO 330FT 100M
HARDWARE
Cabling
Cat 5 UTP
Ports
4
PERFORMANCE
Maximum Cable Length
328 ft (100 m)
Maximum Data Transfer Rate
480 Mbps
CONNECTOR(S)
Local Unit Connectors
1 - RJ-45 Female
1 - USB B (4 pin) Female
Remote Unit Connectors
1 - RJ-45 Female
4 - USB Type-A (4 pin) USB 2.0 Female
SOFTWARE
OS Compatibility
OS Independent, No additional drivers or software required
SPECIAL NOTES / REQUIREMENTS
System and Cable Requirements
USB enabled computer system with available USB port
INDICATORS
LED Indicators
1 - Activity
1 - Host Connection
1 - Link
1 - Power
4 - USB Link
POWER
Center Tip Polarity
Positive Input Current
0.58 A Input Voltage
100 - 240 AC Output Current
1A Output Voltage
24 DC Plug Type
M Power Consumption (In Watts)
15 Power Source
AC Adapter Included
ENVIRONMENTAL
Humidity
10 - 90% RH Operating Temperature
0oC to 50oC (32oF to 122oF) Storage Temperature
-20oC to 70oC (-4oF to 158oF)
PHYSICAL CHARACTERISTICS
Color
Black
Material
Aluminum and Plastic
