Specifications

• Mfr Part Number: TL-WPA4220KIT
• Features:
  • Wi-Fi Clone Button simplifies your Wi-Fi configuration and helps build a seamless unified home network
  • HomePlug AV standard providing up to 500Mbps high speed data transmission over a home's existing electrical wiring, ideal for lag-free HD or 3D video streaming and online gaming
  • Extend 300Mbps wireless connections to previously hard-to-reach areas of your home and office
  • Two Ethernet ports allow your TVs, game consoles, or PCs connect to the Internet
  • Up to 300-meter range over the household power circuit
  • Easy to install, just plug in and play
  • 128-bit AES encryption easily at a push of "Pair" Button
  • Supports IGMP managed multicast IP transmission, optimizing IPTV streaming
• Hardware Features:
  • Standards and Protocols: HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n
  • Interface: 2x 10/100Mbps Ethernet Ports
  • Plug Type: EU, US, UK, AR
  • Button: Pair, Reset, Wi-Fi/Wi-Fi Clone
  • LED Indicator: PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone
  • Power Consumption: < 6W
  • Range: 300M over electrical circuit
  • Dimensions (WxDxH): 3.7 x 2.1 x 1.6 inch / 94.0 x 54.0 x 40.0 mm
• Software Features:
  • Modulation Technology: OFDM (PLC)
  • Encryption: Powerline Security - 128-bit AES Encryption; Wireless Security - WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption
• Others:
  • Certifications: CE, FCC, RoHS
  • Package Contents: Powerline Ethernet Adapter TL-WPA4220 & TL-PA4010; 6.5ft Ethernet Cable (RJ45); Resource CD; Quick Installation Guide
  • System Requirements: Windows 8/ 7/ Vista/ XP/ 2000/ 2003, Mac, Linux
  • Environment:
    • Operating Temperature: 0^oC~40^oC (32^oF~104^oF)
    • Storage Temperature: -40^oC~70^oC (-40^oF~158^oF)
    • Operating Humidity: 10%~90% non-condensing
    • Storage Humidity: 5%~90% non-condensing
