Output
Output power capacity:700Watts / 1.0 kVA
Max Configurable Power (Watts):700Watts / 1.0 kVA
Nominal Output Voltage:120V
Output Voltage Distortion:Less than 5%
Output Frequency (sync to mains):50/60Hz +/- 3 Hz
Other Output Voltages:110, 127
Load Crest Factor:3 : 1
Topology:Line Interactive
Waveform type:Sine wave
Output Connections (6) NEMA 5-15R (Battery Backup)
Transfer Time:6ms typical : 10ms maximum
Input
Nominal Input Voltage: 120V
Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections: NEMA 5-15P
Cord Length: 8ft ( 2.44meters ) Input voltage range for main operations 82 - 144V
Input voltage adjustable range for mains operation:75 - 154V
Number of Power Cords :1
Other Input Voltages: 110, 127
Batteries Runtime
Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time :3hour(s)
Communications Management
Interface Port(s):SmartSlot , USB
Control panel:Multi-function LCD status and control console
Audible Alarm:Alarm when on battery : distinctive low battery alarm : configurable delays
Emergency Power Off (EPO):
Available SmartSlot Interface Quantity:1
Surge Protection and Filtering
Surge energy rating :680Joules
Filtering:Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Item Dimension (L inchxW inchxH inch)
24 x 10 x 24 Weight
69.20lb Warranty Information
3 years repair or replace (excluding battery) and 2 year for battery
