StarTech NETRS232Brand NewIncludes 2 Year WarrantyProduct # NETRS232Connect, configure and manage a remote RS-232 serial device, over an IP network. The NETRS232 Serial Device Server lets you remotely access and manage an RS232 serial device over a local or wide area network (LAN/WAN), giving you a simple and cost-effective serial-over-IP control solution. For installation flexibility across a variety of locations or environments, you can power the serial device server using either a 12V DC power adapter (included) or through the integrated 10~30V DC terminal block. Plus, the device server is DIN rail mountable for out-of-the-way installations. To help ensure seamless performance and prevent possible damage to the server and connected devices, the serial device server offers 15KV ESD (Electrostatic Discharge) protection. This highly-customizable device server is easy to configure to suit your application, with versatile browser-based or Virtual Com port software configuration and integrates support for VCOM, TCP Server/Client, UDP, HTTP, DHCP, ICMP(PING), Static IP, and ARP protocols, while supporting baud rates up to 230.4 Kbps and is compliant with IEEE 802.3, IEEE 802.3u standards. Backed by a 2-year StarTech.com warranty and free lifetime technical support. NETRS232 Features: Media Type Supported: Twisted Pair Wireless LAN: No Ethernet Technology: Fast Ethernet Network Standard: 10/100Base-TX Network (RJ-45): Yes USB: No Serial Port: Yes Parallel Port: No Centronics Port: No PoE (RJ-45) Port: No Number of Network (RJ-45) Ports: 1 Number of Serial Ports: 1 Form Factor: Rail-mountable Green Compliant: Yes Green Compliance Certificate/Authority: RoHS

Hardware
Ports:1
Interface:Serial
Industry Standards:IEEE 802.3, IEEE 802.3u Connector(s)
Connector Type(s):
1 - DB-9 (9 pin D-Sub) Male
1 - RJ-45 Female
1 - Terminal Block (2 Wire) Performance
Serial Protocol:RS-232
Max Baud Rate:230.4 Kbps
Data Bits:5, 6, 7, 8
Flow Control:RTS/CTS, None
Parity:None, Even, Odd, Space, Mark
Stop Bits:1, 1.5, 2
Remote Management Ability:Yes
Surge Protection:15KV ESD (Electrostatic Discharge) Protection
Compatible Networks:10/100 Mbps
Auto MDIX:Yes
Supported Protocols:VCOM, TCP Server, TCP Client, UDP, HTTP,DHCP, ICMP(PING), Static IP, ARP Software
OS Compatibility:
Windows 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64), 2000
Windows Server 2012, 2008 R2, 2003 (32/64)

Color
Black

Enclosure Type
Plastic Indicators
LED Indicators:
1 - Power
1 - Tx
1 - Rx
1 - 10/100Mbps LAN
1 - Link/Activity Power
Input Voltage:100 240 AC
Input Current:480 mA
Output Voltage:12 DC
Output Current:1.2 A
Center Tip Polarity:Positive
Power Consumption:1.45W Max Included in Package
1 - Serial over IP Device Server
1 - DIN Rail Kit
1 - Terminal Block
1 - Universal Power Adapter (NA/UK/EU)
1 - Software CD
1 - Instruction Manual Item Dimension (L"xW"xH"):
6.69 x 6.10 x 3.15

Weight:
0.95 lb

Warranty Information:
2 Years Warranty
