8-Port Console Server with Dual GB NIC, 4G, Flash & 4 USB Ports

Simple and Flexible Accessibility Eight serial RS-232 console ports are configured to use standard Cat5e/6 patch cable when connecting to Cisco devices. They integrate with industry-standard directory servers using TACACS+, RADIUS, LDAP and Kerberos authentication. Provides 4Gb of internal NAND flash memory.Connect an External Modem for Out-of-Band Access Connect one of the eight RS-232 ports to an external Multitech MT9234MU-CDC-XT or US Robotics USR5637 USB modem (sold separately) to receive out-of-band (alternate channel) access when remote sites experience a network outage.Router/Gateway Each gateway can port forward to an unlimited number of locally networked hosts (computers, routers). This rack console also includes a built-in stateful firewall and embedded DHCP server to host a separate management LAN for critical traffic.The Utmost in Security to Keep Your Sensitive Data Private The B093-008-2E4U supports the following security features and standards: PCI DSS 3.2, FIPS 140-2, SSL and SSH, stateful firewall, OpenVPN and IPSec VPN support. The embedded FIPS 140-2 OpenSSL cryptographic module is validated to meet FIPS 140-2 standards and has received Certificate #2473.PowerMan PDU and UPS Support This 8-port console server uses PowerMan for PDU and RPC management and Network UPS Tools for UPS system monitoring and management. It provides support for Tripp Lite and other power products, so you can remotely manage power to your connected equipment.USB Console and Digital I/O (DIO) Ports Four USB 2.0 console ports allow connection to newer devices with USB console ports, such as Tripp Lite’s wide variety of PDUs and UPS systems with WEBCARDLX and LX Platform remote management cards. Two DIO ports are included for connecting compatible devices, such as drive relays and alarms.Compact Design for Convenient Mounting The heavy-duty steel housing comes with mounting brackets for easy installation in an EIA-standard 19-inch rack. Its fanless form factor also allows desktop deployment on four included rubber feet that help prevent the unit from sliding.TAA-Compliant for GSA Schedule Purchases This serial console server is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.Typical Applications Securely access and control servers, routers, KVM switches and other serial-connected devices in your data center 24/7 Manage diverse server and device platforms using a network connection Oversee IT infrastructure remotely via network Troubleshoot equipment issues without spending time/money traveling to remote locationsPackage Includes B093-008-2E4U 8-Port Serial Console Server with Dual GbE NIC, 4Gb Flash and 4 USB Ports Terminal block DB9F to RJ45 crossover serial adapter External power supply w/4 ft. cord (Input: 100–240V, 50/60 Hz, 0.4A; Output: 12V 1.25A) (4) International plug adapters (North America, Europe, U.K., Australia) Rack-mounting hardware (4) Rubber feet Quick Start GuideRack console for remotely accessing and controlling serial-based networking equipment through one highly secure gateway. Manage routers, UPS systems and other serial-based equipment from anywhere at any time 24/7 Validated to meet FIPS 140-2 standards to ensure utmost protection of private data Dual Gigabit Ethernet ports for primary network connection and automatic failover Designed for standard Cat5e/6 patch cable when connecting to Cisco devices Easy installation on desktop or 19 in. racks using included mounting hardwareMulti-User YesINPUT Voltage Compatibility (VAC) 100; 110; 120; 127; 200; 208; 220; 230; 240 External Power Supply Input Specs (V / Hz / A) 100-240V/ 50/60Hz / 0.4A External Power Supply Output Specs (V / A) 12V / 1.25A External Power Supply Cord Length (ft.) 4 External Power Supply Cord Length (m.) 1 External Power Supply Plug(s) NEMA 1-15P North America; CEE 7/16 Schuko; BS 1363 UK; AS/NZS 3112 Australia External Power Supply Certifications CE; FCC; UL; TUV; PSE; C-Tick; GS; RoHS; CBUSER INTERFACE, ALERTS & CONTROLS LED Indicators 7 LED's for Power, Heartbeat-Firmware Running, Serial Connectivity and Network PortsPHYSICAL Unit Packaging Type Box Unit Dimensions (hwd / cm) 2.86 x 8.89 x 10.16 Unit Weight (kg) 0.45 Material of Construction Metal Color Black Rackmountable YesENVIRONMENTAL Operating Temperature Range -13 to 140 F (-25 to 60 C) Storage Temperature Range -40 to 167 F (-40 to 75 C) Relative Humidity 5% to 90% RH, Non-Condensing BTUs 39.2 BTU/Hr Power Consumption (Watts) 11.5COMMUNICATIONS IP Remote Access Yes Network Speed 1Gbps IEEE Standards Supported 802.3; 802.3ab; 802.3adCONNECTIONS Ports 8 Side A - Connector 1 (2) RJ45 (FEMALE) Side B - Connector 1 (8) RJ45 (FEMALE); (4) USB A (FEMALE)FEATURES & SPECIFICATIONS Port Selection GUI USB Specification USB 2.0 (up to 480 Mbps) Driver Required No Authentication Supported RADIUS; LDAP; TACACS Common Access Card (CAC) Support NoCERTIFICATIONS Certifications Tested to CE, FCC, UL, TUV, C-Tick, RoHS, REACH
