Output
Nominal Output Voltage:240V
Overload Protection:Yes
Maximum Total Current Draw:24
Output Connections:(12) IEC 320 C19 (Battery Backup)
(30) IEC 320 C13 (Battery Backup)
Input
Nominal Input Voltage:400V 3PH
Input frequency:50/60 Hz
Input Connections:IEC 309 30A 3P+N+E
Cord Length:6ft ( 1.83meters )
Number of Power Cords:1
Load Capacity:17300VA
Maximum Input Current:30A
Maximum Line Current:30A
Regulatory Derated Input Current (North America):24A
Physical
Color:Black
Environmental
Operating Temperature:32 - 131 oF ( 0 - 55 oC )
Operating Relative Humidity:5 - 95 %
Operating Elevation:0-10000ft ( 0-3000meters )
Storage Temperature:-25 - 65 oC
Storage Relative Humidity:5 - 95 %
Storage Elevation:0-50000ft ( 0-15000meters )
Conformance
Approvals:cUL Listed, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Class A, ICES-003, UL Listed, VCCI Class A
Sustainable Offer Status
RoHS:Compliant
REACH:REACH: Contains No SVHCs
Battery Directive:Compliant
Battery Notes:ts_Battery_Notes
Item Dimension (L inchxW inchxH inch)
5 x 85 x 9 Weight
29.92lb Warranty Information
2 years repair or replace
