S M 308 Power Supply Unit - 300W, ATX Compatible
  • Cost: $201.47
  • Quantity: 1
  • Free Shipping
  • Views:
  • Sold and Shipped By: eforgo

The S M 308 Power Supply Unit is designed to deliver reliable and efficient power to your system. With a total power output of 300W, it provides ample power for various components while ensuring stability and security with multiple protection features.

This power supply is compatible with Pentium 4 systems and encompasses advanced technology for superior performance. It boasts a quiet operation with a controlled fan and features robustness against short circuits and over voltages.
  • Specifications compliance: TFX 12V v2.31
  • Pentium 4 ready with P4 connectors
  • Forward converter circuit for efficient power delivery
  • High efficiency and reliability
  • Low ripple and noise for stable operation
  • Super low noise fan control
  • Short circuit protection on all outputs
  • Over voltage protection
  • Over power protection
  • 100% hipot test
  • 100% burn in high temperature cycled on/off
  • Total Power: 300 W
  • Input Voltage: 100-240 V
  • Input Frequency Range: 47 - 63 Hz
  • Input Current: 5A max
  • Inrush Current: 100A max cold start
  • Holdup Time: 12 ms
  • Power Factor Correction: Active PFC 99% typical
  • Safety approvals: CUL, TUV, CB, EMIRFI, CE, FCC, Ctick
  • Outputs: +3.3V (20A), +5V (20A), +12V (21A), -12V (0.8A), +5VSB (2A)
  • Connectors: 1x 20/24-pin Main, 1x 4-pin 12V CPU, SATA, HDD, FDD
  • Cooling System: 1x 8cm Double Ball Bearing Fan
  • Dimensions (WxLxH): 3.3 x 6.9 x 2.8 inches (85 x 175 x 70 mm)
  • RoHS Compliant
